Hysteresisograph & Gauss Meter
 |
|
- Testing sample varieties: soft magnetic ferrite, permalloy, amorphous, nm crystal, iron dust core, electrician ferrite and stalloy.
- Testing sample shapes: annular, E and U closing samples, and strip (bar) and chip open samples.
- Closing sample direct winding measurement: sample, magnetizing coil (N1) and measuring coil (N2) form a no-load transformer.
- Measure magnetic field intensity through measuring magnetizing current, magnetic field lock precision as high as 0.1%.
- Adopt electronic integrator to measure magnetic induction, zero drift of integrator can be self-corrected through software.
- Solenoid or permeameter shall be equipped to measure open samples.
- Testing method: simulate ballistic method and magnetic field sweep.
- Adopt analog ballistic method to measure basic magnetization curve, can accurately measure magnetic characteristic parameters on magnetization curve: ¦Ìi, ¦Ìm, Bs, value ¦Ì of any point.
- Adopt analog ballistic method and magnetic field sweep to measure saturation hysteresis loop, can accurately measure magnetic characteristic parameters on hysteresis loop: Bs, Br, Hc and Pu. Special explanation: simulate ballistic method to measure hysteresis loop is an exclusive measuring method of our company, can greatly improve the accuracy of Hc and Br.
- Automatic demagnetization function before ¦Ìi testing, 10Hz AC saturation demagnetization adopted.
- Testing single parameter can be selected in case of measurement with analog ballistic method to save time, the time of every testing point can be set as 0.1 second ~ 0.9 second.
- The density of testing point can be self-regulated with B speed feedback according to the shape of sample magnetic characteristic curve; curve can be also tested according to the testing point predefined by users.
- Powerful software functions with minimal technical requirements for testing staff.
|
|
| Gauss meter |
 |
Gauss meter measures the surface magnet of permanent magnet, residual magnetism of weak magnetic materials surrounding magnetic field and so on.
Possesses the functions of determinating polarity,locking peak value, presetting separation and alarm.
Measuring accessorie remote control interface, especially suitable of automatic assembly line operation.
According to the necessity to choose various types of probe. |
|
