Magnetizer
Application for Magnetizer.

For NbFeB, Ferrite and the other general magnetism material.

For NbFeB, Ferrite, rubber magnetism board¡¯s multilevel magnet.

For NbFeB or ferrite ¡¯loudspeaker.

CONDENSER TYPE OF MAGNETIZER

HIGH VOLTAGE, LOW CAPACITOR, SPEED DISCHARGE, FULL ELEC. CIRCUIT SYSTEM, HIGH EFFICIENCY AND STABILITY DIGITAL CONTROL SYSTEM.



1,000-2,000V series


FOR MULTIPLE POLES MAGNETIZATION OF ALL KINDS MAGNET ESPECIALLY, DC MICRO MOTOR ASSEMBLY BY MULTIPLE POLE OF RARE- EARTH MAGNET OR FERRITE MAGNET.


MD- X100V X100uF ---- D: Demagnetizer    C: Super Current    N: Normal Current

Spec\Model MD1010 MD1020 MD1510 MD1520 MD2010 MD2020
input
power supply		 AC220V
20A 		AC220V
30A 		AC220V
30A 		AC220V
30A 		AC220V
30A 		AC220V
30A
output voltage DC100-1000V DC100-1000V DC100-1500V DC100-1500V DC100-2000V DC100-2000V
output current 5KA-20KA 5KA-20KA 5KA-20KA 5KA-20KA 5KA-30KA 5KA-30KA
Electrostaic capacity 1000 uF 2000 uF 1000 uF 2000 uF 1000 uF 2000 uF
charging time 1-10 sec 1-15 sec 2-20 sec 2-25 sec 3-35 sec 3-35 sec
cycle used 2-20 sec 2-25 sec 3-30 sec 3-35 sec 4-45 sec 4-45 sec
weight 150kg 150kg 150kg 170kg 160kg 180kg
Dimensions
L x W x H		 600X700X1400 600X700X1400 600X700X1400 600X700X1400 600X700X1400 600X700X1400
  CUSTOM SPECIAL SPECIFICATION ACCEPTABLE

2,500-3,500V series


FOR LARGE SIZE MAGNETS MAGNETIZATION THE BEST EQUIPMENT FOR WHOLE SIZE RING TYPE AND ARC SEGMENT OF FERRITE OF RARE-EARTH MAGNET, SINGLE POLE; MULTIPLE POLES AXIAL OR RADIUS MAGNETIZATION.

MD- X100V X100uF ---- D: Demagnetizer    C: Super Current    N: Normal Current

Spec\Model MD2510 MD2520 MD3020 MD3030 MD3520 MD3540
input
power supply		 AC220V
40A 		AC220V
50A 		AC220V
50A 		AC220V
75A 		AC220V
60A 		AC220V
80A
output voltage DC100-2500V DC100-2500V DC100-3000V DC100-3000V DC100-3500V DC100-3500V
output current 3KA-30KA 3KA-30KA 3KA-30KA 3KA-30KA 3KA-30KA 3KA-30KA
Electrostaic capacity 1000 uF 2000 uF 2000 uF 3000 uF 2000 uF 4000 uF
charging time 5-20 sec 7-25 sec 8-30 sec 10-30 sec 15-35 sec 20-35 sec
cycle used 6-30 sec 8-35 sec 9-40 sec 11-40 sec 16-50 sec 21-50 sec
weight 250kg 460kg 500kg 600kg 600kg 720kg
Dimensions
L x W x H		 700X800X1800 1000X800X1800 1000X800X1800 1300X800X1800 1000X800X1800 1600X800X1800
  CUSTOM SPECIAL SPECIFICATION ACCEPTABLE

A/900V5000-30000uF450V 20000uF ~ 150000MF series


THIS SERIAL EQUIPMENT SUITABLE FOR HIGH INTRINSIC COERCIVE FORCE MAGNETS FULL SATURATION USAGE, ESPECIALLY, FOR HYSTERESISGRAPH TESTING(B-H CURVE TEST).

MD- X100V X100uF

Spec\Model MD0950 MD09100 MD09150 MD09200 MD09250 MD09300
input
power supply		 AC220V
30A 		AC220V
30A 		AC220V
45A 		AC220V
50A 		AC220V
50A 		AC220V
75A
output voltage DC50-900V DC50-900V DC50-900V DC50-900V DC50-900V DC50-900V
output current 3KA-10KA 3KA-10KA 3KA-10KA 3KA-15KA 3KA-15KA 3KA-20KA
Electrostaic capacity 5000 uF 10000 uF 15000 uF 20000 uF 25000 uF 30000 uF
charging
time		 3-15 sec 3.5-15 sec 4-20 sec 6-25 sec 8-30 sec 10-30 sec
cycle used 4-20 sec 4.5-20 sec 5-25 sec 7-30 sec 9-35 sec 11-35 sec
weight 150kg 160kg 190kg 210kg 230kg 250kg
Dimensions
H X W X L		 1200X600X900 1000X800X1800 1200X600X900 1200X600X900 1200X600X900 1200X600X900
  CUSTOM SPECIAL SPECIFICATION ACCEPTABLE

A/900V5000-30000uF450V 20000uF ~ 150000MF series


THIS SERIAL EQUIPMENT SUITABLE FOR HIGH INTRINSIC COERCIVE FORCE MAGNETS FULL SATURATION USAGE, ESPECIALLY, FOR HYSTERESISGRAPH TESTING(B-H CURVE TEST).

MD- X10V X100ouF   L (x 1000MF)

Spec\Model MD4520L MD4540L MD4560L MD4580L MD45100L MD45150L
input
power supply		 AC220V
30A 		AC220V
30A 		AC220V
45A 		AC220V
50A 		AC220V
50A 		AC220V
75A
output voltage DC50-450V DC50-450V DC50-450V DC50-450V DC50-450V DC50-450V
output current 3KA-10KA 3KA-10KA 3KA-10KA 3KA-10KA 3KA-10KA 3KA-20KA
Electrostaic
capacity		 2000 uF 40000 uF 60000 uF 80000 uF 100000 uF 150000 uF
charging time 3-30 sec 3.5-30 sec 4-40 sec 6-40 sec 8-40 sec 10-50 sec
cycle used 4-35 sec 4.5-35 sec 5-45 sec 7-45 sec 9-45 sec 11-55 sec
weight 150kg 160kg 190kg 210kg 230kg 250kg
Dimensions
H X W X L		 300X500X400 300X500X400 350X600X700 1200X600X900 1200X600X900 1200X600X900
  CUSTOM SPECIAL SPECIFICATION ACCEPTABLE

1500-2000V/1000-3000uF


1,500- 2,000V/1,000-3,000 uF MAG, AND DEMAG. TWO SYSTEMS IN ONE FACILITY SWITCH OVER USAGE FOR ALL KIND OF MAGNETS. THE BEST CHOICE FOR INCREASING YIELD RATE AND CAPABILITY.

Spec\Model MDD1510 MDD1520 MDD1530 MDD2010 MDD2020 MDD2030
input
power supply		 AC220V
30A 		AC220V
30A 		AC220V
40A 		AC220V
30A 		AC220V
30A 		AC220V
40A
output voltage DC100-1500V DC100-1500V DC100-1500V DC200-2000V DC200-2000V DC200-2000V
output current 10000A max 10000A max 10000A max 10000A max 10000A max 30000A max
Electrostaic
capacity		 1000 uF 2000 uF 3000 uF 1000 uF 2000 uF 3000 uF
charging time 2 sec 2.5 sec 3 sec 3.5 sec 5 sec 6.5 sec
cycle used 3 sec 3.5 sec 4 sec 4.5 sec 6 sec 7.5 sec
weight 160kg 180kg 200kg 170kg 190kg 210kg
Dimensions
H X W X L		 700X600X900 950X600X900 950X600X900 1200X600X900 1200X600X900 1200X600X900
  CUSTOM SPECIAL SPECIFICATION ACCEPTABLE
